Answer
Jan 29, 2017 - 01:13 PM
For 3-way you mean 2-way plus intermediate? if so then yes. 2-way or 2-way plus intermediate is just the same. Ideally you need to place the Dimmer 2 module behind the switch that has the live feed and the return to the lamp. In you current (pre-module) setup you should see these two wires connected to L1 and L2 on the switch along with the wires that go off to the next switch in the line. Live goes into L the module, the return to the lamp goes into the switches output on the module. You the add two short wires. One between Sx on the Dimmer 2 and L1 on the switch. Another between S1 on the module and S2 on the switch. for this setup you also need to set the dimmer 2for Toggle switches (parameter 20=1) and disable S2 operation (parameter 26=0).
I can't link to the diagram, but of you google fibaro uk wiring diagrams,the one you need is on the 3rd page.
I can't link to the diagram, but of you google fibaro uk wiring diagrams,the one you need is on the 3rd page.
